| 227IEC52(RVV) 2x0.5-0.75mm2 |
| 227IEC53(RVV) 2x0.75mm2 |
| View Drawing |
|
| 227IEC53(RVV) 2x0.75-1.0mm2 |
| 245IEC53(YZ) 2x0.75-1.0mm2 |
| 245IEC57(YZW) 2x0.75-1.0mm2 |
| View Drawing |
|
|
| |
|
| |
 |
 |
| |
|
| 227IEC53(RVV) 3x0.75-1.0mm2 |
| 245IEC53(YZ) 3x0.75-1.0mm2 |
| 245IEC57(YZW) 3x0.75-1.0mm2 |
| View Drawing |
|
| 227IEC53(RVV) 3x1.0-1.5mm2 |
| 245IEC53(YZ) 3x1.0-1.5mm2 |
| 245IEC57(YZW) 3x1.0-1.5mm2 |
| 245IEC66(YCW) 3x1.0-1.5mm2 |
| View Drawing |
|
|
| |
|
| |
 |
 |
| |
|
| H03VV-F 2x0.5-0.75mm2 |
| H03VVH2-F 2x0.5-0.75mm2 |
| H05VV-F 2x0.75-1.0mm2 |
| H05VVH2-F 2x0.75-1.0mm2 |
| H05RR-F 2x0.75-1.0mm2 |
| H05RN-F 2x0.75-1.0mm2 |
| View Drawing |
|
| H03VV-F 2x0.5-0.75mm2 |
| H03VVH2-F 2x0.5-0.75mm2 |
| H05VV-F 2x0.75-1.5mm2 |
| H05VVH2-F 2x0.5-0.75mm2 |
| H05RR-F 2x0.75mm2 |
| View Drawing |
|
|
| |
|
| |
 |
 |
| |
|
| H03VV-F 2x0.75mm2 |
| H03VVH2-F 2x0.75mm2 |
| H05VV-F 2x0.75-1.5mm2 |
| H05VVH2-F 2x0.75-1.5mm2 |
| H05RR-F 2x0.75-1.5mm2 |
| H05RN-F 2x0.75-1.0mm2 |
| View Drawing |
|
| H03VV-F 3G0.5-0.75mm2 |
| H05VV-F 3G0.75-1.5mm2 |
| H03RT-F 3G0.75-1.0mm2 |
| H05RR-F 3G0.75-1.5mm2 |
| H05RN-F 3G0.75-1.0mm2 |
| H07RN-F 3G1.0-1.5mm2 |
| View Drawing |
|
|
| |
|
| |
|
| |
|
