| 250/250
FLAT FLEXIBLE CORDS |
| CONDUCTOR |
INSULATION |
JACKET |
| No.of
core |
sectional
area
(mm2) |
Nom.
Thick
(mm) |
Nom.
Diam.
(mm) |
Nom.Thick
(mm) |
Nom.Diam.
(mm) |
| 2 |
0.5 |
0.8 |
- |
- |
3.0x5.7 |
| 0.75 |
0.8 |
- |
- |
3.3x6.3 |
| 250/440
FLAT FLEXIBLE CORDS |
| 2 |
0.5 |
0.6 |
- |
- |
4.2x6.3 |
| 0.75 |
0.6 |
- |
- |
4.6x7.0 |
| 250/440
ORDINARY DUTY FLEXIBLE CORDS |
| 2 |
0.75 |
0.6 |
2.35 |
0.8 |
7.0 |
| 1.0 |
0.6 |
2.55 |
0.8 |
7.2 |
| 1.5 |
0.7 |
3.00 |
0.8 |
8.2 |
| 2.5 |
0.8 |
3.65 |
1.0 |
10.1 |
| 3 |
0.75 |
0.6 |
2.35 |
0.8 |
7.4 |
| 1.0 |
0.6 |
2.55 |
0.8 |
7.6 |
| 1.5 |
0.7 |
3.00 |
0.9 |
8.9 |
| 2.5 |
0.8 |
3.65 |
1.1 |
10.10 |
| 4 |
0.75 |
0.6 |
2.35 |
0.8 |
8.0 |
| 1.0 |
0.6 |
2.55 |
0.8 |
8.5 |
| 1.5 |
0.7 |
3.00 |
0.9 |
10.0 |
| 2.5 |
0.8 |
3.65 |
1.1 |
11.9 |
|
| |
|
| |
 |
| |
|
| |
| 0.6/1KV
HEAVY DUTY FLEXIBLE CORDS |
| CONDUCTOR |
INSULATION |
JACKET |
| No.of
core |
sectional
area
(mm2) |
Nom.
Thick
(mm) |
Nom.
Diam.
(mm) |
Nom.Thick
(mm) |
Nom.Diam.
(mm) |
| 2 |
0.75 |
0.8 |
2.55 |
1.3 |
8.8 |
| 1.0 |
0.8 |
2.75 |
1.3 |
9.2 |
| 1.5 |
0.8 |
3.20 |
1.5 |
10.1 |
| 2.5 |
0.9 |
3.85 |
1.7 |
11.9 |
| 3 |
0.75 |
0.8 |
2.55 |
1.4 |
9.5 |
| 1.0 |
0.8 |
2.75 |
1.4 |
9.8 |
| 1.5 |
0.8 |
3.20 |
1.6 |
10.8 |
| 2.5 |
0.9 |
3.85 |
1.8 |
12.8 |
| 4 |
0.75 |
0.8 |
2.55 |
1.5 |
10.5 |
| 1.0 |
0.8 |
2.75 |
1.5 |
10.7 |
| 1.5 |
0.8 |
3.20 |
1.7 |
11.8 |
| 2.5 |
0.9 |
3.85 |
1.9 |
14.0 |
|
| |
|
| |
|
| |
|
